Composite Rabatdeel -Ashwood

Per panel:

• - Standard dimension: L 290 cm × W 22.2 cm. Some colors available in multiple dimensions; please ensure you select the correct dimension when ordering.
• - Working width: 20 cm (Note: this is the visible width)
• - Thickness: 2.5 cm
• - Area per rebate panel: 0.58 m² (for L 290 cm)

WPC (Wood Plastic Composite). The material is a composition of wood + plastic composite: a combination of wood fibers and plastic.

Includes 10-year manufacturer's warranty

1. First, start with the dimensions of the outdoor surface where the Composite Cladding will be installed.
Example situation: Rear facade of a house with a length of 15 meters and a height of 2.9 meters
Calculation:
• 1 Composite panel = 2.90 meters and its area is: 0.58m2
• (15 meters x 2.9 meters) ÷ 0.58m2 meters = 75 composite cladding panels

• OR 15 meters ÷ 0.20 meters = 75 composite cladding panels
Please note: the width of a composite panel is: 0.22 meters, but if you want to calculate the quantity, you divide it by 0.20 meters, as this is the working width. The 0.02 meters (2cm) is for the screw section and that goes under the adjoining panel.

Also consider whether the following products are needed: aluminium profiles, end profiles or corner profiles for a neat and seamless finish of the composite cladding.

2. Then order in our webshop.

What is WPC composite?

Shiplap cladding made from WPC composite material is an excellent alternative to traditional wood. The material is a wood-plastic composite: a combination of wood fibers and plastic. The material used lasts significantly longer and requires almost no maintenance. Although WPC composite is more expensive to purchase than wood, it offers significant advantages that make this investment more than worthwhile.

WPC composite adds a modern and neat appearance to your outdoor space. The initial investment pays for itself through its long lifespan, minimal maintenance costs, and excellent performance compared to standard wooden cladding.

Co-extrusion technology applied

Co-extrusion technology has been applied to this product. This technology ensures high color fastness, extra wear resistance, and excellent resistance to weathering. This means the facade cladding remains beautiful for a long time, even when exposed to sun, rain, and temperature fluctuations. Compared to traditional wooden cladding, composite is dimensionally stable, more resistant to moisture, and requires significantly less maintenance.

In addition, the tongue-and-groove system has been improved, which ensures easy and pleasant installation.

By using WPC facade cladding, your garden shed, chalet, outbuilding, or commercial property, for example, immediately gets a fresh and modern look.

Advantages of WPC composite

• ✅ WPC composite is more stable, harder, and more resistant to weathering and shocks than traditional wood.
• ✅ WPC composite is completely waterproof, so moisture has no negative impact on the panels.
• ✅ Thanks to its clever design, the facade cladding is quick and easy to install.
• ✅ Wood-plastic composite is flame-retardant, unlike standard wooden facade cladding.

WPC composite facade cladding – low maintenance and strong

Suitable for various applications

WPC composite facade cladding is perfect for:

• Homes
• Commercial properties
• Sheds
• Riding schools
• Garden sheds
• Chalets
• Tiny houses
• Modular units

Frequently Asked Questions about Composite Cladding

What is composite cladding or composite tongue and groove paneling?

A composite tongue and groove panel, also called composite cladding or composite exterior panel, is cladding made of WPC (Wood Plastic Composite), a mix of recycled wood fibers and plastic. This material combines the natural look of wood with the durability and low maintenance of plastic.

Why choose Composite Cladding?

The colors and texture of Composite Cladding provide a luxurious, dark wood look with a natural grain, perfectly suited for modern and classic architecture. The finish adds extra depth and character to the appearance.

Installation and assembly

How do I install the tongue and groove panels?

The tongue and groove panels are primarily installed vertically on a sub-construction or framework using special mounting clips or screws. We recommend having the installation performed by a professional or following our detailed installation manual. Please contact us for specific installation instructions. For the installation manual, please visit: https://www.prismartconstructies.nl/pages/montage-handleiding

What kind of sub-construction do I need?

For composite tongue and groove panels, we recommend a wooden batten/wooden framework as a sub-construction with a maximum center distance of 40 cm. This ensures optimal stability and ventilation.

Can I install the tongue and groove panels myself?

Yes, with the right tools and instructions, it is possible to install the tongue and groove panels yourself. Some DIY experience is advisable. For a perfect result, we recommend professional installation.

Maintenance and durability

How much maintenance do the tongue and groove panels require?

Minimal! The tongue and groove panels do not need to be painted, varnished, or impregnated. An annual cleaning with water and mild soap is sufficient to keep them looking like new.

How long do the tongue and groove panels last?

Our composite tongue and groove panels have a lifespan of 25+ years and come with a 10-year manufacturer's warranty. They are resistant to all weather conditions and retain their color and shape.

Do the tongue and groove panels fade in the sun?

The tongue and groove panels are UV-resistant and colorfast. A slight natural discoloration may occur in the first few months, after which the color remains stable. This is normal and falls within the warranty conditions.

Are the tongue and groove panels frost-resistant?

Yes, the composite tongue and groove panels are completely frost-resistant and can withstand temperatures from -40°C to +60°C without problems.

Technical specifications

What dimensions are available?

The composite tongue and groove panels are available in:

• 290 cm × 22.2 cm (working width 20 cm = visible width)

The thickness is 2.5 cm. These exterior panels are also available in different sizes: 240cm, 340cm, and 390cm. All with a width of 22.2 cm.

How many tongue and groove panels do I need for my project?

One 290 cm tongue and groove panel covers approximately 0.58 m². Calculate your required area and divide it by 0.58 to determine the number of planks. Always account for 10% extra for cutting loss and reserve.

What is the working width?

The working width (the visible width after installation) is 20 cm. The total width of the tongue and groove panel is 22.2 cm.

Warranty and service

What warranty do I get?

Composite Cladding comes with a 10-year manufacturer's warranty against production defects, color fading, and structural flaws under normal use and correct maintenance.

What is not covered by the warranty?

Damage due to incorrect installation, mechanical damage, storm damage, or the use of incorrect cleaning agents or extreme conditions are not covered by the warranty.

Ordering and delivery

How quickly can I receive the tongue and groove panels?

Delivery time depends on stock and your location. Please contact us on WhatsApp: +31 6 16237086 for current delivery times and availability. Generally, we deliver within 2 to 5 business days.

Can I receive samples?

Yes, we can provide samples so you can assess the color and quality before ordering. To order samples, click on this link: https://www.prismartconstructies.nl/collections/samples-alle-kleuren. Please contact us for more information.

Do you also supply the necessary installation accessories?

Yes, we supply all necessary installation accessories such as mounting screws, corner, and finishing profiles. Ask for a complete package for your project.
1. For end profiles, see: https://www.prismartconstructies.nl/collections/composiet-eindprofielen.

2. For composite corner profiles, see:
https://www.prismartconstructies.nl/collections/composiet-hoekprofielen.

3. For aluminum finishing profiles, see:

https://www.prismartconstructies.nl/collections/aluminium-profielen

Any more questions?

Is your question not listed? Feel free to contact us. Our team will be happy to help you with tailored advice for your project!
